Carlson SurvCE is a complete data collection system for Real Time (RTK) GPS and Total Stations with in-field coordinate geometry. It supports the widest range of popular and new release RTK GPS and conventional/ robotic total stations.
Major New Features and Improvements: SurvCE 6.0
SurvCE now offers the Hybrid+ Survey module to survey with both GPS and Total Station at the same time. Visit www.survce.com/hybrid for more details.
Log Raw GPS has been redesigned to allow static logging without configuring an RTK Rover or Base. The process has been streamlined for ease of use.
SurvCE now offers an advanced total station search icon to allow selection of search type from inside of any live survey screen.
GNSS Analysis has been updated to the 2017 version.
SurvCE now supports a laser pointer icon in all live survey screens for any total station with a laser pointer.
SurvCE now supports web map overlays from Google, Open Street Maps and ArcGIS REST. SurvPC additionally supports user-defined Web Map Servers (WMS/WMTS/TMS).
SurvCE can now read and export PRJ projection files.
SurvCE now includes Snap options inside of store points to facilitate drawing in the field as part of the survey process. An UNDO option has also been included.
Total station control icons Search, Lock/Track, Target, and Laser Pointer will now be available in more screens.
A new status icon will now show the status of the instrument connection from all screens.
SurvCE now includes a “GIS Inspector” feature in the Map screen that allows viewing and editing GIS attributes as linework is created and edited.
SurvCE now supports obstructed view stakeout mode.
SurvCE now includes a “Surface Inspector” for elevation difference which allows storing and staking points from the surface as well as viewing cut/fill to the surface using Snaps.
SurvCE now displays a red tolerance bar to indicate that a measurement is currently outside of a user defined tolerance.
SurvCE now supports an automatic backsight check in the joystick screen.
Auto by Interval when level now stores the most level reading which was recorded during the required level tolerance period.
SurvCE now supports continuous reflectorless measurement for total stations which support the feature.
SurvCE now offers the ability to demo the roading module on an already registered copy of the software.
SurvCE now supports a two-prism pole in the 2-Point offset routine.
Just a few of the powerful features to help you get your job done faster and better:
Advanced Roading: favored by U.S. DOTs and heavy highway contractors around the world
Cutting-edge functionality for staking intersections and cul-de-sacs using Carlson Road Network files
Optional Field-to-Finish: Create drawings intuitively and automatically as you work, saving you time back in the office
Highly graphical and intuitive user interface is designed ‘by surveyors for surveyors’
Strong GIS features for accurate data capture, including attribute data and seamless linking to Esri®
Easy data exchange due to rich support of CAD file formats and .dwg, .dgn, .shp
More field capabilities with quick and easy volume calculation and ability to generate points from polylines
Cut/Fill stakeout using surface files
Camera integration allowing assignment of picture to points or lines
Export directly in KML format for fast control in Google Earth
True versatility: SurvCE and SurvPC run on hundreds of GPS and total station models in service today, including Altus, Ashtech, Carlson, Geomax, Leica, Pentax, Sokkia, Spectra-Precision, Stonex, Topcon, and more. See full list at www.survce.com.
SurvCE/PC are available in more than two dozen languages: English, Spanish, German, French, French (Canadian), Russian, Portuguese, Czech, Dutch, Chinese, Korean, Greek, Italian, Polish, Hungarian, Swedish, Latvian and more.
SurvCE/PC 6.0 deliver on accuracy and efficiency:
Enhanced Search icon now available in all live survey screens with access to multiple search methods for TS/RTS
Voice prompting In Stakeout allows users to keep their eyes on the environment while staking
Google, Open Street Maps, Esri® Maps, and your own WMS overlays now available in the field
GIS Inspector allows instant access to GIS attributing in the map screen
Surface Inspector enables easy comparison of plan vs. asbuilt in elevation difference, making it simpler to store and stake the points that matter
Obstructed Point Stakeout allows guided staking of unreachable points by marking azimuth and distance
Automatic Backsight Check in the joystick screen makes it easier to check your setup at any time
GPS Tolerance Band instantly indicates when a tolerance is exceeded in live survey screens
All-new Hybrid+ module combines the power of RTS and GNSS providing the most reliable and fast survey techniques on the market:
Mix and match any RTS and GNSS from Carlson’s vast driver library
GPS Search is faster than any search method available
Follow Me keeps the total station pointed where you need it by continuously tracking the GNSS location
Smart Lock detects when you are slowing down to take a measurement and automatically locks on the prism—ready when you are
Smart Staking provides directions from the GNSS when the total station position isn’t available, then automatically locks back on the prism when you reach your destination
Backup Tracking — GPS position is automatically shown when total station is not tracking
GNSS Sensors work with the total station to allow e-level in total station mode and automatic correction of tilted poles
