GEODE GNS2 COMPATIBILITY
- iPhone 11 Pro Max, iPhone 11 Pro, iPhone 11, iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8, iPhone 8 Plus, iPhone 7, iPhone 7 Plus, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPod Touch (7th generation), iPad mini (5th generation), iPad (7th generation), iPad (6th Generation), iPad Pro 12.9 inch (3rd Generation), iPad Pro 12.9 inch (2nd Generation), iPad Pro 12.9 inch (1st Generation), iPad Pro 11-inch, iPad Pro 10.5 inch
- Windows® PC (8/10)
- Windows® Embedded Handheld 6.5
- Android™ 4.x and above
- GeodeConnect™ software provides configuration, communications setup, and receiver settings
RECEIVER PROTOCOLS
- Data I/O protocol: NMEA 0183, raw binary (proprietary), RTCM3
- Other: 1PPS timing output, Speed Pulse, event marker input (optional)
ACCURACY
- SBAS (WAAS): <30 cm horizontal RMS (<60 cm 2DRMS)*
- Cold start: <60 sec typical (no almanac)
- Reacquisition: <1 sec
*GNSS accuracy subject to observation conditions, multipath environment, number of satellites in view, satellite geometry, and ionospheric activity.
POWER
- Input voltage: 5VDC @ 2A USB
- Power consumption: 1.7-2 W nominal
- Overtime Technology™ battery: 3.6V 6000 mAh Li-ion (~10-11 hours typical)
- Charging time: ~4 hours typical
ANTENNA
- Internal precision multi-GNSS with integrated ground plane
- External antenna port: MCX type, 50 ohm 15VDC @ 20 mA maximum
JUNIPER RUGGED™
- 2 year warranty
- Operating temperature: -20 C to +60 C
- Storage temperature: -30 C to +60 C
- Enclosure rating: IP68
- Dimensions: 4.4 x 4.4 x 1.7 inch (111 x 111 x 43 mm)
- Weight: 0.8 lb (360 g)
- Mount: ¼ x 20 camera stud and #6-32 AMPS Adapter (diagonal)
COMMUNICATIONS
- Bluetooth® 4.1 (SPP, iAP2, and EAP)
- Bluetooth® range: Class 1 Long Range
- Ports: micro USB Client 2.0; serial RS232C DB-9 (optional)
- Serial baud rates: 4800-115200
RECEIVER UPGRADES
- 2 Hz to 10 Hz update rate
- Multi-GNSS upgrade
SOFTWARE
- GeodeConnect™: provides configuration, communications setup, and receiver settings
- Available for:
- iPhone and iPad (see Geode GNS2 Compatibility for complete list of devices)
- Windows Embedded Handheld 6.5
- Android 4.x and above
- Windows PC (8/10)
RECEIVER
- Receiver type: GNSS single frequency with carrier tracking
- Signals received: GPS, SBAS,GLONASS, BeiDou, GALILEO, and QZSS. (*Signals used dependent on model configuration.)
- Channels: 162
- SBAS tracking: 3-channel parallel tracking
- Update rate: 1 Hz standard, 2-10 Hz (optional)
INCLUDED ACCESSORIES
- 5VDC USB Universal Charger
- USB Data/Charging Cable (USB-A to Micro-B)
- 5/8 x 11 Pole Mount Adapter
